The benefits
- Automatically dilutes cleaning chemical concentrates.
- Bottle activated.
- Back-Flow prevention.
- Suitable for water pressure from 15psi minimum, up to 130psi maximum.
- Suitable for water temperatures of up to 70C degrees.
- Robust heavy duty plastic (will not rust or corrode).
- Quick and easy to install.
- The compact modular design fits any installation.
- Less wall space needed.
- Horizontal mount and / or in corners.
- Security locking screw for front cover.
- Complete installation kit.
- A water supply is required for this product to operate.
Dilution options
This filling station comes with 15 dilution tips that are used to deliver different dilution ratios you might require. Each dilution tip has a different colour for easy identification.
For 4L/min bottle fill
Requires minimum 16L/min water flow from source to obtain 4L/min.
Colour Dilution Diameter (mm) Grams / Litre %
No Tip 2:1 - 412 41
Grey 2.5:1 3.250 383 38
Black 3:1 2.540 359 36
Beige 4:1 1.780 266 27
Red 6:1 1.320 165 17
White 9:1 1.090 107 11
Blue 11:1 1.010 95 10
Tan 14:1 0.880 71 7
Green 20:1 0.710 50 5
Orange 24:1 0.630 42 4
Brown 35:1 0.580 28 3
Yellow 37:1 0.510 27 2.5
Aqua 46:1 0.460 22 2
Purple 91:1 0.360 11 1
Pink 182:1 0.250 6 0.5
Clear 0 0 0 0
